A PCB layer is not a sketch. It is an imaging program.
Parse Gerber format and units, aperture definitions/selections, coordinates, D01 draws, D02 moves, D03 flashes, polarity, and file end; produce an object ledger, millimeter bounds, undefined-aperture checks, and a lightweight preview.
Open the workbench ↓01 · WORKBENCH
Inputs and files stay on this device
02 · CAPABILITIES
Built deeply for one narrow workflow
Aperture, draw, and flash state
Object bounds and layer preview
The tool covers a common modern-Gerber subset. It does not replace Ucamco's Reference Viewer, full PEG validation, aperture macros, regions, attribute semantics, step-repeat, or fabricator CAM review. Recheck the complete dataset before production.
